Chapter 3 Display Operations Menu Operations
52 Series PM172 Powermeters
2. You are returned to the upper window to select another
analog output or exit the menu.
To exit the menu, press ESC.
The following table lists available analog output options.
Label Parameter Options Description
OutP Output
parameter
See Appendix B
Selects the measured parameter to
be transmitted through the analog
expander channel.
Lo Zero scale Low engineering scale (in primary
units) for the analog output
corresponding to a lowest (zero)
output current (0 or 4 mA)
Hi Full scale High engineering scale (in primary
units) for the analog output
corresponding to a highest output
current (1 or 20 mA)
Ì Analog expander outputs will not be operational until you globally enable the
analog expander option in your meter through the Device Options menu.
Timers Setup
The PM172E and PM172EH are provided with two interval timers. When
enabled, a timer generates periodic events in predefined intervals that can
trigger setpoints to produce periodic actions like periodic data trending. To
enter the menu, select the “t-r” entry from the Main menu and press the
ENTER button.
Use the UP and DOWN arrow buttons to scroll to the desired timer.
To change the time period for the timer:
1. Press the SELECT button to activate the lower window.
2. Use the UP and DOWN arrow buttons to enter the desired interval value
in seconds. Intervals from 1 to 9999 seconds are allowed. Resetting the
interval to 0 disables the timer.
3. Press ENTER to confirm your changes and to save the new settings, or
press ESC to discard changes.
4. You are returned to the middle window to select another timer or exit the
menu.
To exit the menu, press ESC.
Display Setup
This menu allows you to configure options for the meter display, and view
display and device firmware versions. To enter the menu, select the “diSP”
entry from the Main menu and press the ENTER button.
To select a setup option:
1. Press the SELECT button to activate the middle window.
2. Use the UP and DOWN arrow buttons to scroll to the desired option.
To change the option:
1. Press the SELECT button to activate the lower window.
2. Use the UP and DOWN arrow buttons to select the desired option.
3. Press ENTER to confirm your changes and to save the new setting, or
press ESC to discard changes.
To exit the menu, press ESC.
t-r
0
t-r.1
diSP
1.0
UPdt
