Chapter 4 PAS Application Software Configuring Recorders
92 Series PM172 Powermeters
The following table lists available waveform options.
Option Format/Range Description
Samples per Cycle
32, for Waveform Log #1
128, for Waveform Log #2
Fixed for the file
Cycles per Series
16-2560 (32 samples/cycle),
4-640 (128 samples/cycle)
Defines the total duration of the
waveform per event/series
Before Cycles
1-20
Defines the number of cycles to be
recorded prior to event
Num. of Channels
6
Fixed. Shows the number of the
simultaneously recorded channels
6. Select the number of cycles to be recorded prior to the
event, and a total number of cycles in the waveform.
7. Add the name for your waveform log file in the “Name”
box. It will appear in the waveform reports.
8. Save you waveform setup to the device database, and
send it to the meter.
