Hardware manual PCD7.LRxx-PG5 room controller │ Document 27-653; version ENG07 │ 2019-03-21
Saia-Burgess Controls AG
Sylk bus FBoxes
Room operating devices
7-7
7
parameters. The default address is 1. If only one PCD7.LR-TRxx module is con-
nected to the Sylk bus, the default values are correctly preset in the FBoxes.
If multiple PCD7.LR-TRxx devices (max. four) are used, the Sylk bus address in
the FBox and on the associated device must be set to the same value using the
DIP switch. Permissible Sylk bus addresses are 1 to 4.
A corrective value can be set for each measured value in the FBox. The received
value from the PCD7.LR-TR40-xxx is displayed with this correction both in the
Depending on the desired function, the display can still be controlled.
The setpoint can be set as an absolute value (e.g. 18.0 to 28.0) or as a cor-
rective value (e.g. -3.0 to +3.0). In the case of an absolute value, the value is
displayed; for corrective values, a slider with +/- is displayed.
Rel. humidity, if available, can be displayed on the home screen or when cy-
cling through the available values.
Air quality in CO2 ppm, if available, can be displayed on the home screen or
when cycling through the available values.
The adjustment option for the fan can be completely deactivated so that no icon
can be seen on the display. If this is activated, the user can choose between
Manual operation by the user can be disabled completely. If this is enabled, the
user can manually set the presence using the top right key. An additional hand
output.
Home screen. When the default display is set to home screen, the value to be
-
onds.
If none of the aforementioned inputs is active, the room is unoccupied, and the
"little man" icon is outside his house.
