Hardware manual PCD7.LRxx-PG5 room controller │ Document 27-653; version ENG07 │ 2019-03-21
Saia-Burgess Controls AG Communication
5
5-9
RS-485 interfaces (ports 0 + 1) in general
LRxx-P5 room controller:
E-Line functions
(FBoxes)
Registers Flags
Program
size
Size of RAM
data blocks
DB RAM
[Lines] * [Byte]
EL + S-Bus master 196 119 547 2064 2
PCD1.A1000 54 124 1753 168 1
PCD1.A2000 40 90 1493 120 1
PCD1.B1000 38 127 1315 60 1
PCD1.B1010 38 147 1315 60 1
PCD1.B1020 32 91 1147 36 1
PCD1.B5000 37 72 1433 112 1
PCD1.B5010 37 72 1433 112 1
PCD1.E1000 42 45 687 60 1
PCD1.G2000 70 58 2177 200 1
PCD1.G2100 44 33 957 108 1
PCD1.G2200 76 62 1929 208 1
PCD1.G5000 84 135 2191 196 1
PCD1.G5010 121 111 2415 276 1
PCD1.G5020 106 95 2391 276 1
PCD1.W5200 94 82 1722 172 1
* Program line corresponds to four-byte memory.
These tables are developed from measurements for library E-Line 1.3.007; any
adjustment to the library may result in a deviation from the estimates below.
This data is provided as an estimate; they are not exact values.
