Function
Light tube adjustment sets the mechanical alignment of the optical
system (light source and sensor).
Technical data
TP46 - test point
TP100 - ground
Tools and equipment required
C-spanner for light unit lock ring
2 mm allen key for lamp cover and back cover mounting screws
2.5 mm allen key for focus motor mounting screws
3 mm allen key (T-handle) for right hand drum cover mounting screws
Extension board (part of the service kit)
Voltmeter with probes
5 • ADJUSTMENTS AND TESTING
Light Tube
Edition 1 January 1996 Service Manual • ScanMate 4000/5000
5•2a
Caution! Turn off power • Before connecting or disconnecting cables.
• Before carrying out service operations.
When the hardware drawer is partially removed and power turned
on, ensure that the open side of the heat sink on the driver board
is covered, with, for example a piece of cardboard or paper, in
order that cooling is still effective.
