SCANVIEW ScanMate 5000 - Access Panels

To Next Page

To Previous Page

Covers and panels

A Lamp cover

B Back cover

C Right hand end plate

D Right hand drum cover

E Left hand end plate

F left hand drum cover

Tools required

2.5 mm allen key (long) for lamp cover

3 mm allen key (T-handle) for left and right hand drum cover screws

3 mm allen key for left and right hand end plate mounting screws

2 mm allen key for back cover mounting screws

3 mm allen key for end plate mounting screws

4 • PART REPLACEMENT

(4000 and 5000) Access Panels

Edition 1 • January 1996 Service Manual • ScanMate 4000/5000

4•2a

Caution! ☛ Turn off power • Before connecting or disconnecting cables.

• Before carrying out service operations.
