Function
The spindle step motor is common to the ScanMate 4000 and 5000
(both 0200 and 0210 models), and rotates the spindle which moves the
drum to its left (park), right (zero) and lock positions. The speed of
spindle rotation is dependent on the resolution of the actual scan.
Technical data
VEXTA single shaft PH265 step motor.
6 V, 0.85 current per phase.
Tools and materials required
3 mm allen key (T-handle) for left hand drum cover
3 mm allen key for end plate and motor mounting screws
Loctite 222 or equivalent for motor shaft mounting screw
4 mm lock washer
4 • PART REPLACEMENT
PN 960 20 000 90 (4000 and 5000) Spindle Step Motor
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
4•14a
Caution! ☛ Turn off power • Before connecting or disconnecting cables.
• Before carrying out service operations.
