Function
The halogen lamps are common to both the 4000 and 5000 models and
are the source of light when scanning originals.
Light from the transmission lamp is transmitted through a fibre optics
cable to the light tube.
Light from the reflection lamp is transmitted through a fibre optics cab-
le to the sensor module.
Technical data
Halogen projector lamps 12V, 75W
Tools and materials required
2.5 mm allen key (long) for lamp cover mounting screws
4 • PART REPLACEMENT
PN 920 20 000 20 (4000 and 5000) Halogen Lamps
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
4•3a
Caution! ☛ Turn off power • Before connecting or disconnecting cables.
• Before carrying out service operations.
☛ The lamps will be very hot if the scanner has been running, there-
fore take care when removing.
