Function
The CPU module is common to the ScanMate 4000 and 5000, (both
0200 and 0210 models) and contains the CPU and memory, EPROM
and SCSI controller.
Technical data
-----
Tools and materials required
2 mm allen key for back cover and hardware unit mounting screws
4 • PART REPLACEMENT
PN 960 20 000 20 (4000 and 5000) CPU Board
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
4•7a
Caution! ☛ Turn off power • Before connecting or disconnecting cables.
