Function
There are three identical amplifier boards, but they differ between the
ScanMate 4000 and 5000, (both 0200 and 0210 models), however remo-
val and assembly is identical.
They are mounted on the control board and contain the A/D converters.
Their function is to amplify RGB signal data
Technical data
PN 960 25 000 30 SM 4000
PN 960 20 000 30 SM 5000 (0200 and 0210 models)
Tools and materials required
2 mm allen key for back cover and hardware unit mounting screws
4 • PART REPLACEMENT
PN 960 25 000 30 (4000) Amplifier Board
PN 960 20 000 30 (5000)
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
4•9a
Caution! ☛ Turn off power • Before connecting or disconnecting cables.
• Before carrying out service operations.
