Function
The sensor module is common to both the 4000 and 5000 models and
transforms light from the scans and separates the beam into RGB light.
Technical data
-----
Tools and materials required
1.5 mm allen key for fibre optic cables set screws
2 mm allen key for sensor optics holder
2.5 mm allen key for lamp cover and back cover mounting screws
3.0 mm allen key (T-handle) for right hand drum cover mounting screws
3 mm allen key for end plate and sensor mounting bracket screws
4 • PART REPLACEMENT
PN 960 20 001 10 (4000 and 5000) Sensor Module
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
4•4a
Caution! ☛ Turn off power • Before connecting or disconnecting cables.
• Before carrying out service operations.
