Function
The indicator display is common to the ScanMate 4000 and 5000, (both
0200 and 0210 models) and combines selection touch-switches with the
status lights.
Technical data
-----
Tools and materials required
2.5 mm allen key for internal protection cover.
3 mm allen key (T-handle) for left and right hand drum cover mounting
screws.
3 mm allen key for end plate
Isopropylalcohol
4 • PART REPLACEMENT
PN 960 20 000 70 (4000 and 5000) Indicator Display
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
4•12a
Caution! ☛ Turn off power • Before connecting or disconnecting cables.
• Before carrying out service operations.
