Now to replace
Removal
1 Remove the following covers:
Right hand end plate C, right hand drum cover D, left hand end
plate E and left hand drum cover F, (section 4•2 steps 3 and 6).
2 Remove the four 3 mm allen screws A, (two each side of the drum),
securing the internal protection cover.
3 Slide the cover to the right, (viewed from the front of the scanner),
in order to give access to the back of the indicator display.
4 Carefully pull the display ribbon cable away from its adhesive pad
and disconnect the connector.
5 Using a small screwdriver or other suitable tool, peel the indicator
display away from the scanner.
Assembly
6 Clean the area on the cabinet where the new display is to be fitted,
with isopropyl alcohol.
7 Peel the protective paper from the back of the new display, feed the
ribbon cable through the opening in the drum and firmly press the
display into place.
8 Reconnect the connector and press the ribbon cable down onto
the adhesive pad.
9 Position the internal protection cover and secure it with the four 3
mm allen screws A, (two each side of the drum).
10 If no further replacement operations are required, refit the covers
removed in step 1 in accordance with section 4•2.
Adjustments required
No adjustments are necessary.
Service Manual • ScanMate 4000/5000 Edition 1 January 1996
Indicator Display
4•12b
