Unpacking and installation
1 • Check the Tip-N-Tell and Shockwatch indicators on the container
before unpacking.
Note: if the indicators show that the container has been subject to
mishandling or has been tipped, note this on the Bill of Lading and
contact your freight forwarder.
2 • Lift the Scanner out of its container by the base only.
Note: damage will occur to the scanner if it is lifted by the drum.
3 • Place on a firm surface (avoid obstructing the ventilation ducts at
the rear of the scanner).
4 • Continue with hardware installation by refering to section 1 in the
ScanMate 4000and 5000 Operators Manual.
5 • Perform a focus calibration by refering to section 5•4.
Service Manual • ScanMate 4000/5000 Edition 1 • January 1996
2•4
2 • INSTALLATION
Caution! ☛ Turn off power before connecting or disconnecting SCSI cables.
