Pre-installation Requirements
The following mains installations are required:
Electrical wall outlet: 100-240 VAC, 50-60 Hz
ScanMate 4000 and 5000 Dimensions
Caution! ☛ The ScanMate 4000 and 5000 are Class 1 electrical equipment. For
personal safety they must be connected to a single phase mains out-
let with a protective ground, (earth) in accordance with national and
local regulations.
840 mm (33”)
410 mm (16”)
340 mm (13”)
410 mm (16”)
840 mm (33”)
SM 4000
SM 5000
