How to remove
1 • Lamp cover A is a secured by two dome head 3 mm allen screws to
the back cover B. Remove by loosening the two allen screws,
(access is through the ventilation slots, as shown on the diagram
on the cover) and slide the cover off towards the rear.
2 • Back cover B is secured by nine 2.5 mm allen screws along the
back edge. First remove the lamp cover A, and disconnect the con-
nector to the cooling fan. Remove the nine allen screws, slide the
cover towards the rear and carefully lift it away.
3 • Right hand end plate C is secured by one 4 mm countersunk allen
screw underneath the drum cover D. Remove the allen screw and
lift the plate away from the drum cover.
4 • Right hand drum cover D is secured by four 3 mm allen screws on
the inside of the cover securing it to the the frame. First remove
the end plate C, remove the four allen screws and washers and lift
the cover away.
5 • Left hand end plate E is secured by one 4 mm countersunk allen
screw underneath the drum cover F. Remove the allen screw and
lift the plate away from the drum cover.
6 • Left hand drum cover F is secured by four 3 mm allen screws on
the inside of the cover securing it to the frame. First remove the
end plate E, remove the four allen screws and washers and lift the
cover away.
How to replace
7 • Refitment of the covers and plates are carried out in the reverse
order to that of removal.
Service Manual • ScanMate 4000/5000 Edition 1 • January 1996
Access Panels
4•2b
