How to adjust
Note : ScanView recommends that these calibration procedures
are carried out every 3 scanning hours and when the transmission
or reflection bulbs have been changed.
1 • Fit a terminator to a SCSI connector on the scanner and SCSI cable
and RS 232 service cable to the scanner and PC.
2 • Set theDip switch to 8, (on).
3 • Turn on the Mac or PC and scanner and access the service pro-
gram main menu (section 3•5).
4 • Select S, (Turn on SCSI).
5 • Access Photoshop plug-in.
Transmission (Fig. 1)
6 • Select Transmission.
7 • Make a preview.
8 • Crop a square of approximately 20 x 20 mm (1” x 1”) on a clean
and clear area of the drum.
9 • Press the alt key to access calibrate.
10 • Click on Calibrate and the scanner will now calibrate for approx-
imately 3 minutes.
Note: the calibration takes place on the top line of the cropped
area.
Reflection (Fig. 2)
11 • Mount a piece of white paper onto the drum.
Note: The same type or whiter than the most frequently used orig-
inals.
12 • Select Reflection.
13 • Make a preview.
14 • Crop a square of approximately 20 x 20 mm (1” x 1”) on the paper.
15 • Press the alt key to access calibrate.
16 • Click on Calibrate and the scanner will now calibrate for approx-
imately 3 minutes..
Note: the calibration takes place on the top line of the cropped
area.
Service Manual • ScanMate 4000/5000 Edition 1 • January 1996
White Calibration in Transmission and Reflection
5•5b
