4 • PART REPLACEMENT
CPU Board
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
4•7c
CPU
board
2.5 mm
countersunk
screws A
Hardware
unit
SCSI controller
Enlarged drawing of
CPU board in section
7•6
