4 • PART REPLACEMENT
PMT Module
Edition 1 • January 1996 Service Manual • ScanMate 4000/5000
4•11c
PMT module
rotated 180°
Potentiometers
Green cable
connection
Black cable
connection
PMT
module
Allen screw
B
3 mm set
screws
A
Hardware
unit
Control board
Sensor module
