How to replace
Removal - main compartment, 4000 and 5000, (0210 model)
1 • Open the front cover and remove the drum, if mounted.
2 • Remove the plastic cover by pulling it away from its two retaining
magnets. (It may be necessary to very carefully use a screwdriver
under one edge).
3 • Rotate the tube 90° (in either direction), lift upwards and remove.
Assembly - main compartment, 4000 and 5000, (0210 model)
4 • Mount a new tube and rotate it 90° (in either direction) to the
locked position.
5 • Refit the plastic cover.
Removal - auxilliary compartment, 5000, (0200 and 0210 model)
1 • Open the hinged cover and remove the spare drum, if mounted.
2 • Remove the plastic cover by holding in the middle and carefully
pulling away from the two end flanges.
3 • Rotate the tube 90° (in either direction), lift upwards and remove.
Note: it may be necessary to use a small screwdriver between the
fitting and the tube (between the two pins on the tube), in order
to rotate the tube. However we recommend that this method is only
used if rotation cannot be carried out by hand.
Assembly - auxilliary compartment, 5000, (0200 and 0210 model)
4 • Mount a new tube and rotate it 90° (in either direction) to the locked
position.
5 • Refit the plastic cover.
Adjustments required
No adjustments are required.
Service Manual • ScanMate 4000/5000 Edition 1 • January 1996
Fluorescent Light Tube
4•13b
