4 • PART REPLACEMENT
DC Motor
Edition 1 January 1996 Service Manual • ScanMate 4000/5000
4•15c
DC motor
Allen screws
B
(x2)
Inner cover
(earlier models)
Inner cover
(later models)
Connector
PCB
Screws D
(x2)
Access hole for
set screws C
2.5 mm allen
screws A
(only later
models)
Drum sleeve
DC motor
Screws E
(x3)
Jumper position
if the green con-
nector is used
There are two different
types of board, (PCB011D
and PCB 011F),however
the jumper positioning is
the same
Jumper position
if the black con-
nector is used
PCB 011F
Green
Black
Fig. 1 Fig. 2
Fig. 3
ScanMate 5000 shown
(SM 4000 is identical)
