How to replace
Removal
Note: avoid touching the acrylic surface of the drum during removal
and installation.
1 • Turn power on.
2 • To lock the drum, press the drum lock symbol on the display indicator.
Note: for the ScanMate 5000 (0210 model), hold the button down for
3-4 seconds.
3 • Wait until the lock lamp remains lit.
4 • Slowly rotate the drum until a click is heard. The drum is now locked.
5 • Remove the drum by holding on the metal sleeve, rotating in the dir-
ection as shown in the diagram, and lift away.
Assembly
Note: for ScanMate 4000 and 5000 (0200 model), mark the drum with
a number between 1 and 10.
6 • Position the drum with the horizontal line uppermost (fig. 1).
7 • Mount the drum on the studs of the drum platform and turn in the
direction as shown in the diagram.
8 • Repeat step 2 and wait for the lock lamp to stop flashing.
Adjustments and tests required
White calibration in transmission and reflection (section 5•5).
Focus calibration (section 5•4).
Service Manual • ScanMate 4000/5000 Edition 1 • January 1996
Drum
4•16b
