Safety and Functional Tester GLP2-i/e
During the test, test object and test leads must not be touched!
The safety measures required by law must be adhered to!
Schleich GmbH * D-58675 Hemer * 0049 / (0)2372 / 9498-0 * 0049 / (0)2372 / 9498-99 *
http://www.schleich.com * info@schleich.com 11
1.2.7 High voltage test
High voltage AC
High voltage: 0 ... 2750V (5500V)AC - supply-sinusoidal AC voltage (true r.m.s.)
Resolution: 1Veff
Voltage monitoring: both minimum and maximum voltage
Test current: >200mA (according to VDE / IEC regulations)
beginning at approx. 1300V
Current measuring: apparent current or active current
Current display: apparent current or active current
Resolution: 0.1mA
Limit current evaluation: apparent current or active current
Limit current pre-setting: 0.1 ... 100mA - freely programmable, as soon as the limit current is exceeded,
there will be a switch-off with optical and acoustical indication
Response time: < 50ms
Burning function: burning without limit current pre-setting, protection
against overload by thermo switch
Minimum current: 0 ... 100mA - freely programmable
Nominal power: >500VA (according to VDE / IEC regulations)
beginning at approx. 500V
Test time: 0.1 seconds ... 24 hours and without time allowance
Switching-on: at zero crossing of mains voltage
Safety: key switch, external safety contact and Emergency Stop
In case of voltages over 5500V, please refer to the offer for technical details.
High voltage DC
For the data of the high-voltage test DC, please refer to the technical details of the offer.
1.2.8 Residual votlage test
automatic residual voltage test
test voltage: max. 260V
test: 1-phase
measuring delay: 5 sec. (freely programmable 1...10sec.)
test repeat: 10 (freely programmable 1...100)
time of test: random, no relation to phase position
graphical indication of the voltage: no
manual residual voltage test
test voltage: max. 260VAC
measuring leads: 4 pcs. incl. 4 pcs. alligator clips
length of measuring lead: 2m
measuring delay: 5 sec. (freely programmable 1...10sec.)
time of test: random, no relation to phase position
graphical indication of the voltage: no
1.2.9 Resistance test
Measuring range: 4 ranges (0...10Ohm / 0...100Ohm / 0...10Kohm / 0...100KOhm)
accuracy: 0.5 % of range
4-wire resistance measurement: yes
