Safety and Functional Tester GLP2-i/e
During the test, test object and test leads must not be touched!
The safety measures required by law must be adhered to!
Schleich GmbH * D-58675 Hemer * 0049 / (0)2372 / 9498-0 * 0049 / (0)2372 / 9498-99 *
http://www.schleich.com * info@schleich.com 7
1.0 Introduction
1.1 Technical data of the tester
Supply voltage : 230V AC (option: 400V AC)
Protection by fuses, GLP2-i : 10Amp (option: 16A, 32A, 64A)
Password upon delivery : 123
1.2 Technical data of the test methods
The test methods listed below are not necessarily integrated into the testing device. Es ist Möglich, dass
eine Variante einer Prüfmethode eine Andere ausschließt.
1.2.1 PE test
Display: Ohm or Volt
Measuring range: 0 ... 1 Ohm / 0 ... 10V
Resistance test: e.g. according to EN60335-1
Voltage drop test: e.g. according to EN60204-1
Resolution: 0.001 Ohm / 0.01V
Accuracy: 0.5% of measuring range
Limit values: 0.01 ... 1 Ohm - freely programmable
Test current: 10A; (option: 30A short-time operation, 30A continuous operation)
Test current - special feature: 1...30A / the test current can be programmed in steps of 1A
Test current regulation: electronic constant-current source and monitored
Test voltage: <6VAC or <12VAC
Frequency of test voltage: 50Hz (depending on the mains of the tester)
Test time: 0.1 ... 60 sec. - freely programmable
(0.1 ... 1 sec. - freely programmable / short-time operation)
1.2.2 Continuity test (2 Wire)
Measuring range: 1 Ohm ... 10K Ohm / accuracy related to the measuring value = 1.5% +- 1 Ohm
Measuring range: 10K Ohm ... 100K Ohm / accuracy related to the measuring value = 2.5% +- 100 Ohm
Test points: L-N / L-PE / N-PE / PE1-probe
1.2.3 Insulation test
Display: in MOhm
Measuring range: 0 ... 1000 MOhm
Resolution: 0.1 Mohm (value < 100 Mohm)
Resolution: 1 Mohm (value > 100 Mohm)
Accuracy: 0..99Mohm 1% of measuring value (U-min 500V)
Accuracy: 100..499Mohm 1,5% of measuring value (U-min 500V)
Accuracy: 500..1000Mohm 2.5% of measuring value (U-min 500V)
Limit values: 0.1 ... 1000 MOhm - freely programmable
Test current: max. 3mA
Test voltage: 30V ... 1000V / programmable in steps of 10V
Test voltage regulation: electronically regulated and monitored
Test time: 0.1 ... 60 sec. - freely programmable
Tests: L+N <->PE, L<->PE, N<->PE, L<->N, probe<->PE, probe<->L+N, probe<->L,
probe <->N, (L+N means that, for the test, L and N are automatically connected inside the tester.)
