Safety and Functional Tester GLP2-i/e
During the test, test object and test leads must not be touched!
The safety measures required by law must be adhered to!
Schleich GmbH * D-58675 Hemer * 0049 / (0)2372 / 9498-0 * 0049 / (0)2372 / 9498-99 *
http://www.schleich.com * info@schleich.com 43
5.5.3.4 Add. process
With the additional process it is possible to control external relays or other or other switching or display
devices. It is also possible to wait for signals from external switches, which are absolutely necessary for a
continuation of the test.
If you set a waiting time without defining an output (input), the following test step will not be started before
this time has elapsed.
The additional process can also be used as Stopp message between two test steps.
Add. Process
Definition
Add. outputs::........: 7
Add. inputs...........: 1
Waiting time..........: 1.0 s
Safety contact........: off
Disable step..........: off
Cancel if no go.......: off
Enter ?
- +
Definition
You can enter a definition for this test step. This definition will be shown on the display during the test. It is
also possible to show a stop message, which is acknowledged by activating a switch (additional input). An
additional process doesn’t produce a result.
Add. outputs
The additional outputs can be switched by entering the numbers 1 to 16. In this step the outputs are
switched on and after switched off again after the test time (waiting time) in this step. Separated by
commas, several outputs can be switched. (e.g. 1,3,12). By entering the symbol I the following outputs in
this step are only switched on and must be switched off again in a later step. By entering the symbol O the
following outputs in this step are only switched off.
Example:
1,3,I4,5,O7,9
In this example the outputs 1 and 3 are switched on for a time period, outputs 4 and 5 are only switched on
and outputs 7 and 9 are only switched off.
Number of selected output(s)
Adjusted waiting time in second
Number of selected input(s)
Definition of the add. process
Function of the safety switch
