Safety and Functional Tester GLP2-i/e
During the test, test object and test leads must not be touched!
The safety measures required by law must be adhered to!
Schleich GmbH * D-58675 Hemer * 0049 / (0)2372 / 9498-0 * 0049 / (0)2372 / 9498-99 *
http://www.schleich.com * info@schleich.com 42
VIS switch for go
VIS switch for no go
Here you can select, which switch is to be used for confirming the visual test if “go” or “no go”. If no switch
is selected here, the switches as indicated in the menu < General data > apply.
In addition, every visual test can be acknowledged via the touch panel.
List of possible switches for the visual test:
Input number Function
1 Start
2 Probe: push-button 1
3 Probe: push-button 2
4 Probe: switch
5 HV Start
6 HV Stop
7 HV Pistol
8 RSP Trigger
15 Key switch 1 (left)
16 Key switch 2 (right)
17 Additional input 1
18 Additional input 2
19 Additional input 3
20 Additional input 4
21 Two-hand switch 1
22 Two-hand switch 2
23 Safety contact HV
24 Safety contact LV
25 Foot switch
26 Emergency Stop
27 Two-hand start
Disable step
on: This test step will not be executed within the process of the test. All other test steps of
the test method remain active.
off: The test step will be executed.
Cancel if no go
on: In case of faulty tests, the test process will be interrupted.
off: In case of faulty tests it will be continued with the next test step.
