Step 4: Remove front case
Remove the screws holding in the front case.
Loosen clasps in the middle of the front case
and then turn over the front case to remove it
.
Step 5: Remove water tray
Remove the screws of electric box cover 1 and
loosen the clasps. Unplug the wiring terminal of
the swing motor and remove the screws holding
the water tray in place. Then remove the water
tray.
Step 6: Remove electric box
Remove the grounding screw of the
evaporator and the screws of the electric box.
Unplug the connecting wire for the indoor
motor. Loosen the clasps of the electric box
and then remove the electric box.
