Seabreeze SHE9H4ZIGX

To Next Page

To Previous Page

100

Step 7: Remove left side plate

Remove the screws fixing chassis and condenser

support to remove the left side plate.

Remove connection screws between evaporator

and the rear case. Slightly adjust the pipe of the

evaporator and then remove the evaporator.
