Seabreeze SHE9H4ZIGX - Page 92

84
Step 16: Remove the isolation sheet assembly
Remove the screws fixing the isolation
sheet assembly and the condenser side
plate to remove the PFC electrical
inductance.
Step 17: Remove compressor
Remove the screw nuts fixing the
compressor feet and chassis with
the spanner, as well as the foot
cushion, to remove the
compressor.
