36
ASSEMBLY AND INSTALLATION
3
Use 1 cord clamp to secure the LAN cable. To prevent
disconnection, make a 15 cm (5.9 in) (approx.) diameter ring
with the LAN cable before afxing it.
"SERVER" STICKER POSITION
5
Install cabinets other than the server machine. Refer to Steps 1 to 4 in "6-4-1" and work in the same order.
6
15 cm (5.9 in) (approx.) diameter ring
CORD CLAMP (1)
4
Afx the "SERVER" sticker to the underside (center) of the server machine's control panel.
To Next Page
