68
TOUCH SLIDER
11
11
Remove 6 screws and take off the touch slider unit.
12
Refer to Steps 2 to 11 and work in reverse order to attach the replacement touch slider unit, and reassemble
the cabinet.
TOUCH SLIDER UNIT
SCREW (6)
M4 x 8, w/at & spring washers
