41
ARM MECHANISM
13
PHOTO 13-2b
13-2c
2. Tighten the wing screw.
3. Follow the above procedures to adjust the sensor
bracket limit on the opposite side.
The sensor bracket limit positions and areas where the UFO mechanism cannot be moved to are as shown in the
illustration.
FIG. 13-2b
WING SCREW
Areas where UFO mechanism
cannot be moved to
.
SENSOR BRACKET HP
SENSOR BRACKET HP
SENSOR BRACKET LIMIT
