MRD 5800 – User Manual
Page 28 (116)
Port +2 and Destination Port +4 for a SMPTE
2022 FEC Matrix.
Filter
Disabled
Enabling Source filtering disables IGMP V3
filtering and allows a user to whitelist a single
IP address for a given multicast and block all
other source IP’s
Filter IP
0.0.0.0 – 255.255.255.255
Source IP for whitelist. All other source IP
addresses are blocked
Include
Used on networks supporting IGMPv3. If this
setting is set to Exclude any streams
originating from the user defined IP
addresses will be rejected. If this setting is
set to Include any streams originating from
the user defined IP addresses will be
received.
Disabled
Enabling Null Stripped allows the MRD 5800
to receive streams that do not contain null
packets. (i.e. VBR TS Streams)
Disabled
Enabling RTP SSRC allows the MRD 5800 to
filter the input by the user defined value. Only
streams containing the user defined value
will be received by the MRD 5800.
The Filter Value the MRD 5800 checks for
before receiving a stream with RTP SSRC.
Delay (ms)
Allows option to set buffer mode to Size in
KB or Delay ms
This setting determines how much data is
received before the MRD 5800 starts
decoding. Increasing this value will allow the
MRD 5800 is receive streams on networks
with high network jitter. Increasing this value
also increases the latency of the MRD 5800.
The buffer delay setting allows the buffer size
to be set by delay time. The Buffer delay time
will be determined by the input data rate.
Mode
Auto
Statistics can be viewed by hitting the +
symbol next to the MPEG/IP option card on
the main window. Selecting Auto will reset
the statistics on a chosen interval. When the
reset occurs, statistical information for that
period will be logged. Selecting Manual will
only clear the statistics by hitting the refresh
button.
(min)
Interval in which the Auto option will reset
and log the statistics displayed on the main
window
