MRD 5800 – User Manual
Page 52 (116)
Latch Timeout (ms)
1-300
Specify a duration for latch mode. Note:
Receiving a Return to Network message will
override the latch timeout.
Setting
Range
Description
State
Enabled
Disabled
Enable or Disable SCTE 35 message
Insertion
PID
0-8191
PID on which the inserted SCTE 35
messages will be inserted
Splice Type
Normal
Immediate
Selects whether the SCTE 35 message will
be of the “splice immediate” type (which can
trigger an instantaneous switch downstream)
or the normal type which uses a PTS-based
preroll value to time the insertion.
Pre-Roll (ms)
0-20000
Configured offset prior to splice point
Event ID (Hex)
0-FFFFFFFF
Unique Event ID for the the SCTE 35
message
Network Event
Out of Network
Return to Network
Select which network transition signal is used
for the SCTE 35 message
Break Duration (ms)
0-95443717
Duration in ms of the Out of Network Break
Unique Program ID
0-65535
Unique program identification within a service
