OmniHub 6/6D– User Manual
Page 150 of 182
Events
Column Name
Description
Name
Defines the error message that will be provided if the instance is
detected.
Location
This will always be “Unit” since these instances are global
Log
A checked box defines which instances will be recorded to the log file.
SNMP Trap
A checked box defines which instances will trigger the OHP-IP-00
module to send a trap message.
Event Logs
