SL MCR DW
103
Mounting the receiver on the ceiling
To mount the receiver on the ceiling, you will need the mount-
ing frame supplied.
Screws and anchors for mounting the product to the
wall are not included with delivery. Use screws and an-
chors that are appropriate for the particular character-
istics of your wall.
▷ Use the included drilling template to mark the drill holes for
ceiling mounting.
▷ Maintain a minimum distance of 1.5 m from the walls.
▷ Screw the mounting frame to the ceiling using four suitable
screws and anchors.
center
line
center
line
top
center
line
wall mount
VESA 100
center
line
>1,5 m
>1,5 m
