MX3500N SIMULATION 7 – 16
5-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of the heater
lamp and the control circuit.
Section
Fusing
Item
Operation
Operation/Procedure
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The selected heater lamp is operated.
When [EXECUTE] button is pressed, the operation is termi-
nated.
5-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of the scanner
lamp and the circuit.
Section
Optical (Image scanning)
Item
Operation
Operation/Procedure
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The target lamp is lighted for 10 sec.
5-4
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of the dis-
charge lamp and the related circuit.
Section
Process
Item
Operation
Operation/Procedure
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The selected discharge lamp is lighted.
6
6-1
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the paper
transport system, the transfer system, the
fusing system (clutches and solenoids) and
the control circuits.
Section
Paper transport section (Transport, paper
exit)
Item
Operation
Operation/Procedure
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The selected load operation is performed.
When [EXECUTE] button is pressed, the operation is termi-
nated.
(*): For the same loads displayed separately depending on normal
rotation and rotation, if they are selected together, normal rotation
is performed.
In addition, if the load is rotating, reverse rotation is not accepted
until the operation is stopped.
HL_UM Heater lamp upper main
HL_LM Heater lamp lower main
HL_E Heater lamp external
HL_ALL All heater lamps ON
OC COPY LAMP OC copy lamp
DSPF COPY LAMP DSPF copy lamp (MX-3501N/4501N only)
SIMULATION

NO.05

02
TEST
HEATER LAMP LOAD SETUP
HL_UM
HL_LM
HL_E
1/1
EXECUTE
0
CLOSE
HL_ALL
SIMULATION

NO.05

03
TEST
COPY LAMP CHECK
OC COPY LAMP DSPF COPY LAMP
1/1
EXECUTE
0
CLOSE
DL_K Discharge lamp K
DL_C Discharge lamp C Same control
DL_M Discharge lamp M
DL_Y Discharge lamp Y
Transport/
imaging
PFM Transport motor
RRM Resist motor
POMF (*) Paper exit motor normal rotation
POMR (*) Paper exit motor reverse rotation
FUM Fusing motor
CPFM Cassette paper feed motor
OSM Shifter motor
WTNM Waste toner drive motor
CPFC Cassette vertical transport clutch
1TURC Primary transfer separation clutch
PCSS Process control shutter solenoid
LSUSS1 LSU shutter solenoid 1
LSUSS2 LSU shutter solenoid 2
Paper feed CLUM1 Cassette 1 lift-up motor
CPUC1 Cassette 1 paper feed clutch
CLUM2 Cassette 2 lift-up motor
CPUC2 Cassette 2 paper feed clutch
MPUC Manual paper feed clutch
MPFS Manual feed take-up solenoid
MPGS Manual feed gate solenoid
0
EXECUTE
SIMULATION NO.05-04
TEST
DISCHARGE LAMP CHECK
1/1
DL_K
DL_C
DL_M DL_Y
CLOSE
To Next Page
