MX3500N SELF DIAG AND TROUBLE CODE 8 – 18
F2-67 Toner supply abnormality (YELLOW)
F2-70 Toner cartridge improper cartridge
detection (BLACK)
F2-71 Toner cartridge improper cartridge
detection (CYAN)
F2-72 Toner cartridge improper cartridge
detection (MAGENTA)
F2-73 Toner cartridge improper cartridge
detection (YELLOW)
F2-74 Toner cartridge CRUM error (BLACK)
F2-75 Toner cartridge CRUM error (CYAN)
F2-76 Toner cartridge CRUM error
(MAGENTA)
Trouble content Toner end with the remaining quantity of 50% or more.
The toner supply time exceeds 3 times as much as
the specified time.
Section PCU
Case 1 Cause Toner motor section connector harness trouble
Check
and
remedy
Check the connector connection of the toner motor
section.
Check the connector harness (TM) connection to the
main PWB.
Case 2 Cause Toner motor and toner density sensor trouble
Check
and
remedy
Check the toner density sensor output. (SIM25-1)
Check that the toner transport pipe is not clogged
between the toner cartridge and the developing unit.
Replace the toner cartridge (CRUM) if necessary.
If replacement of the toner cartridge (CRUM) does not
clear the trouble, check the developing unit.
Trouble content Improper data are detected in the CRUM contents
when the normal CRUM of the cartridge is detected.
Section PCU
Case 1 Cause An improper cartridge is inserted. Toner cartridge
trouble
Check
and
remedy
Replace the toner cartridge.
Trouble content Improper data are detected in the CRUM contents
when the normal CRUM of the cartridge is detected.
Section PCU
Case 1 Cause An improper cartridge is inserted. Toner cartridge
trouble
Check
and
remedy
Replace the toner cartridge.
Trouble content Improper data are detected in the CRUM contents
when the normal CRUM of the cartridge is detected.
Section PCU
Case 1 Cause An improper cartridge is inserted. Toner cartridge
trouble
Check
and
remedy
Replace the toner cartridge.
Trouble content Improper data are detected in the CRUM contents
when the normal CRUM of the cartridge is detected.
Section PCU
Case 1 Cause An improper cartridge is inserted. Toner cartridge
trouble
Check
and
remedy
Replace the toner cartridge.
Trouble content CRUM cannot be read or written.
Section PCU
Case 1 Cause Connection trouble or disconnection of the connector
and the harness between the PCU and the toner
cartridge.
Check
and
remedy
Check the connector and the harness between the
PCU and the toner cartridge.
Case 2 Cause CRUM trouble
Check
and
remedy
Replace the toner cartridge.
Case 3 Cause Control PWB (PCU) trouble
Check
and
remedy
Replace the PCU PWB.
Trouble content CRUM cannot be read or written.
Section PCU
Case 1 Cause Connection trouble or disconnection of the connector
and the harness between the PCU and the toner
cartridge.
Check
and
remedy
Check the connector and the harness between the
PCU and the toner cartridge.
Case 2 Cause CRUM trouble
Check
and
remedy
Replace the toner cartridge.
Case 3 Cause Control PWB (PCU) trouble
Check
and
remedy
Replace the PCU PWB.
Trouble content CRUM cannot be read or written.
Section PCU
Case 1 Cause Connection trouble or disconnection of the connector
and the harness between the PCU and the toner
cartridge.
Check
and
remedy
Check the connector and the harness between the
PCU and the toner cartridge.
Case 2 Cause CRUM trouble
Check
and
remedy
Replace the toner cartridge.
Case 3 Cause Control PWB (PCU) trouble
Check
and
remedy
Replace the PCU PWB.
To Next Page
