SHERCO 125 User Manual

19
ST SERIES
ENGINE DISASSEMBLING
• tilt the inlay t to the rear and remove it to the
top.
• remove base gasket
❱❘ Reeds valve removal
• Undo the 4 CHC screws 1 .
• Remove the reeds valve 2 as well as the gasket 3 .
❱❘ Right side disassembling
❱❘ Clutch cover removal
• Undo the screws 1 .
• Remove the clutch cover 2 .

SHERCO 125 Specifications

General

Starter	Kick starter
Bore x Stroke	54 mm x 54.5 mm
Cooling System	Liquid
Transmission	6-speed
Front Brake	Disc
Rear Brake	Disc
Displacement	124.8 cc
