21
ST SERIES
ENGINE DISASSEMBLING
• Remove coolant pump snap ring
8
.
• With a pair of pliers, pull away the pump shaft in
order to extract the pump body.
❱❘
Clutch and primary drive removal
• Place the tool
1
part number 10986 between the
crankshaft gear and the clutch gear.
• Loosen clutch torx screws
2
and remove them.
• Remove the preload plate
3
.
