SHERCO 125 User Manual

45
ST SERIES
ENGINE ASSEMBLING
• Fit the clutch case and its screws ;
• Be sure to use a new copper washer when
refitting the screw z .
• Fit the clutch cover and its five screws x .
❱❘ Top-end assembling
❱❘Piston fitting
• Place the base gasket 1 .
• Place the inlay 2 lined up with the conrod,
intake side first, taking care to place it in the
detents of the crankcase halves.

SHERCO 125 Specifications

General

Starter	Kick starter
Bore x Stroke	54 mm x 54.5 mm
Cooling System	Liquid
Transmission	6-speed
Front Brake	Disc
Rear Brake	Disc
Displacement	124.8 cc
