SHERCO 125 - Crankshaft Runout Check

32
ST SERIES
❱❘ Crankshaft runout check
• Put the crankshaft on an alignment device,
or V-blocks, and place a dial gauge on the
crankshaft axles, as shown :
•
•
•
• Then slowly rotate the crankshaft. The
difference between measures means the
runout.
• Runout:
Standard: 0.03 mm max.
Maximum runout: 0.05 mm
