SHERCO 125 User Manual

54
ST SERIES
ELECTRICAL
❱❘ Reset TPS
 In case of replacement of Throttle
Position Sensor or the whole throttle
body, it is necessary to proceed a zero
TPS :
 First, connect the shunt Part number
11212 to the two-pins connector, on
the left side of the bike [1].
 Remove the circuit breaker until the fuel
pump starts working, then replace the circuit
breaker [2].
 Remove again the circuit breaker then
twist the throttle grip to Wide Open
Throttle. Once the fuel pump has
ceased working release the throttle and
place the circuit breaker [3].
 Remove the shunt from the two-pin
connector.
1
2
3

SHERCO 125 Specifications

General

Starter	Kick starter
Bore x Stroke	54 mm x 54.5 mm
Cooling System	Liquid
Transmission	6-speed
Front Brake	Disc
Rear Brake	Disc
Displacement	124.8 cc
