SHERCO 125 User Manual

27
ST SERIES
ENGINE DISASSEMBLING
• Remove the central gasket.
• Slightly hitting its end with a rubber mallet,
remove the crankshaft.
❱❘ Gearbox removal
• Once you have done the previous steps, you
may be able to remove the whole gearbox.
• Make sure the shift drum’s snap ring 1 is off.
• Remove the secondary shaft’s snap ring 2 .
• Remove the gear selector shaft’s snap ring 3 .
• Pinching the pawls, remove the gear selector
shaft.
CAUTION
Take care about the gearbox shafts’s trust
shims. They may stick in the crankcase.

SHERCO 125 Specifications

General

Starter	Kick starter
Bore x Stroke	54 mm x 54.5 mm
Cooling System	Liquid
Transmission	6-speed
Front Brake	Disc
Rear Brake	Disc
Displacement	124.8 cc
