10
ST SERIES
CHASSIS
•
Do
a back and forth movement as shown in
the picture to prime the hydraulic system,
until you feel resistance.
•
Compress the fork tube and damping rod
to the maximum.
•
Measure oil level from the top of the tube,
then fill until you reach the desired height.
Oil level : 85mm
•
Undo totally the damping rod nut and
place the cap
•
Tighten the cap
4
with the nut
5
to a
12Nm torque.
•
Tighten the cap to the tube at a 12Nm
torque.
1.4.2 Left side oil change
•
Using a 17mm wrench, undo the cap
6
•
Remove conical spacer
7
.
•
Remove spacer
8
, as well as the
washer placed between it and the spring.
