SHERCO 125 User Manual

49
ST SERIES
TIGHTENING TORQUES
Cylinder head screws 10 N·m
Cylinder base nuts 22 N·m
Ignition cover screws 0,7 N·m
Stator screws 0,7 N·m
Flywheel screw 100 N·m
Pressure plate screws 0,7 N·m
Clutch nut 40 N·m (With medium threadlocker Loctite 243)
Intake boot screws 0,7 N·m
Crankcase halves screws 15 N·m
Primary drive gear nut 60 N·m
M5 screws 0,6 N·m
M6 screws 12 N·m
M8 screws 24 N·m
M10 screws 40 N·m
Rear wheel spindle nut 100 N·m
Front wheel spindle 100 N·m
Bottom steering head nut 20 N·m
Top steering head nut 20 N·m
Swingarm spindle 50 N·m

SHERCO 125 Specifications

General

Starter	Kick starter
Bore x Stroke	54 mm x 54.5 mm
Cooling System	Liquid
Transmission	6-speed
Front Brake	Disc
Rear Brake	Disc
Displacement	124.8 cc
