17
ST SERIES
ENGINE DISASSEMBLING
❱❘ Gearbox draining
•
Remove draining screws
1
and the filler cap
2
,
help the oil flow out by tilting the bike.
❱❘ Front sprocket removal
•
Remove snap ring
3
.
•
Remove front sprocket
4
.
❱❘ Top-end removal
•
Undo the screws
5
and remove
cylinderhead
cover
6
.
•
remove the insert ( combustion chamber)
7
.
