48
ST SERIES
ENGINE ASSEMBLING
❱❘ Reed valve and intake boot
•
Place a new reed valve gasket.
•
Fit the reed valve.
•
Place a new intake boot gasket.
•
Fit the intake boot and tighten its four M5
screws at a 6Nm torque.
❱❘ Gearbox output sprocket
•
Fit the engine-side snap ring.
•
Place the sprocket, the number of teeth
faced outwards .
•
Fit the outside snap ring.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SHERCO 125 and is the answer not in the manual?

SHERCO 125 Specifications

General IconGeneral
StarterKick starter
Bore x Stroke54 mm x 54.5 mm
Cooling SystemLiquid
Transmission6-speed
Front BrakeDisc
Rear BrakeDisc
Displacement124.8 cc
