11
ST SERIES
CHASSIS
•
Remove the spring 9
and clean it
with a cloth.
•
Drain the oil.
•
Put fork leg vertically and pour 250cc of
new oil inside.
•
Do
a back and forth movement as shown in
the picture to prime the hydraulic system,
until you feel resistance.
•
Compress the fork tube and damping rod
to the maximum
.
•
Measure oil level from the top of the tube,
then fill until you reach the desired height.
Oil level : 140mm
•
Reassemble, in this order : the spring, the
washer, the spacer, the conical spacer then the
cap.
•
Place the fork tube in a vise with a suitable
support so as not to damage it and tighten
the cap to
a 12Nm torque.
