22
ST SERIES
ENGINE DISASSEMBLING
• Remove clutch spring
4
.
• Remove pressure plate
5
.
• Remove diaphragm pads
6
.
• Remove the clutch pusher
7
, and the pushrod
• Remove all the discs in one batch, taking care to
keep them in the same position.
• Using the tool Reference 10982 hold the hub and
the basket, to loosen the hub screw
8
.
